Steatite is the most used ceramic material in many insulators and standoffs, as its good thermal and electrical performances, moreover the cost of steatite is much lower when compared with alumina or zirconia. Typical applications include band heater, thermostat, spark electrode and many other insulators (glazed or not). US customers mostly use steatite grade L-3 & L-5, Europe customers mostly use steatite grade C220 & C221, our engineers will support you with all available materials.
The manufacturing process of steatite ceramic:
Ningbo Victor Import And Export Co., Ltd can manufacture steatite ceramic via four different process, include dry pressing, injection moulding, isostatic pressing and extruding. We will manufacture the steatite parts as per customer’s process requirement, or recommend the most cost-effective process.
Properties of steatite ceramic:
Property
Unit
Steatite
Density
g/cm3
2.7
Water Absorption
%
0
Sintering Temperature
°C
1350
Hardness
HV
800
Bending Strength
MPa
90
Compressive Strength
MPa
400
Max Working Temperature
°C
1100
Co-efficient of Thermal Expansion 0-1000°C
/°C
6×10-6
Thermal Shock Resistance
T(°C)
200
Thermal Conductivity
W/m.k (25°C,300°C)
2.5
Volume Resistivity 20°C
Ω.cm
>1012
Dielectric Strength
KV/mm
10
Dielectric Constant (100 Mhz)
(E)
5.8
